Specifications
- Manufacturer: Jayco
- Model: Pinnacle 36FBTS
- Year: 2026
- Type: Fifth Wheels
- Dry Hitch Weight (lbs): 2,535
- Unloaded Vehicle Weight (lbs): 14,255
- Cargo Carrying Capacity (lbs): 3,245
- Gross Vehicle Weight Rating (lbs): 17,500
- Exterior Length (overall): 40' 10"
- Exterior Length (box length): 40' 8"
- Exterior Height: 12' 7"
- Exterior Height (with A/C): 13' 3"
- Exterior Height (with 2nd A/C): 13' 3"
- Exterior Width: 8' 6"
- Exterior Width (with slides out): 14' 6"
- Interior Height (main): 8' 4"
- Interior Height (upper deck): 6' 7"
- Awning Length: 19' 0"
- Awning Length 2: 11' 0"
- Fresh Water Capacity (gals): 75.0
- Gray Water Capacity (gals): 87.0
- Black Tank Capacity (gals): 87.0
- Propane Unit (lbs): 120
- Sleeps: up to 4
- # of outside storage compartments: 2
- Furnace BTU: 40000
- Tire Size: 215/75R17.5'H'
